ZICHAI LB6250ZLD Series Generator Set
The Zichai LB6250ZLD Series generator sets leverage the company’s decades of experience in marine power R&D and manufacturing. With diverse product types and fuel adaptability, these generator sets find extensive applications across industrial, energy, environmental, and infrastructure sectors. Featuring robust construction and reliable operation, the series covers a power range of 700 kW to 1000 kW at speeds of 720 to 750 rpm, ensuring stable and efficient performance under continuous load conditions. Compliant with international and domestic emission standards, this series achieves exceptional fuel efficiency under full load conditions, significantly reducing operational costs. Through optimized maintainability and durability design, these generator sets demonstrate exceptional availability and adaptability in real-world applications.
General Specifications of LB6250ZLD Series
| Rated Power : | 700 – 1000 kW |
| Maximum Power of Diesel Engine : | 880 – 1213 kW |
| Rated Speed : | 720/750 rpm |
| Rated Current : | 1107 – 1803 A |
| Stationary Voltage Regulation Ratio : | ±2.5% (parallel) |
| Fuel Consumption : | 198 g/kW·h |
| Lube Oil Consumption : | 1.0 g/kW·h |
| Weight of Set : | 21000 – 230 00 kg |
| Rated Frequency : | 50/60 Hz |
| 700 kW | ZDMO700PNOA | |||||||
| 700 kW | ZDMO700PNOB | |||||||
| 750 kW | ZDMO750PNOB | |||||||
| 800 kW | ZDMO800PNOA | |||||||
| 850 kW | ZDMO850PNOA | |||||||
| 850 kW | ZDMO850PNOB | |||||||
| 950 kW | ZDMO950PNOA | |||||||
| 1000 kW | ZDMO1000PNOA | |||||||
Engine Model Rated Power/kW | 700 | 750 | 800 | 850 | 900 | 950 | 1000 | 1050 |
Engine Model | Rated Power | Rated Speed | Engine Model | Rated Power | Rated Speed | ||
| ZDMO700PNOA | 700 kw | 750 rpm | ZDMO700PNOB | 700 kw | 720 rpm | ||
| ZDMO750PNOB | 750 kw | 720 rpm | ZDMO800PNOA | 800 kw | 750 rpm | ||
| ZDMO850PNOA | 850 kw | 750 rpm | ZDMO850PNOB | 850 kw | 720 rpm | ||
| ZDMO900PNOA | 900 kw | 750 rpm | ZDMO1000PNOA | 1000 kw | 750 rpm | ||
| ——END—— | |||||||
Zichai LB6250ZLD Series Generator Set
This is the list of all series of Zichai LB6250ZLD Series Generator Set.
ZICHAI ZDMO700PNOA Generator Set
Engine Model: LB6250ZLD-4
Rate Power: 700kW
Continuous Speed: 750 rpm
ZICHAI ZDMO700PNOB Generator Set
Engine Model: LB6250ZLD-14
Rate Power: 700kW
Continuous Speed: 720 rpm
ZICHAI ZDMO750PNOB Generator Set
Engine Model: LB6250ZLD-3
Rate Power: 750kW
Continuous Speed: 720 rpm
ZICHAI ZDMO800PNOA Generator Set
Engine Model: LB6250ZLD-4
Rate Power: 800kW
Continuous Speed: 750 rpm
ZICHAI ZDMO850PNOA Generator Set
Engine Model: LB6250ZLD-6
Rate Power: 850kW
Continuous Speed: 750 rpm
ZICHAI ZDMO850PNOB Generator Set
Engine Model: LB6250ZLD-7
Rate Power: 850kW
Continuous Speed: 720 rpm
ZICHAI ZDMO950PNOA Generator Set
Engine Model: LB6250ZLD-2
Rate Power: 950kW
Continuous Speed: 750 rpm
ZICHAI ZDMO1000PNOA Generator Set
Engine Model: LB6250ZLD-2
Rate Power: 1000kW
Continuous Speed: 750 rpm
