ZICHAI LC8250ZLC Series Marine Engine
The Zichai LC8250ZLC series marine diesel engines are developed based on decades of experience in marine propulsion R&D and manufacturing. Featuring a robust power core, these highly reliable products offer a power range of 732 kW to 1960 kW and a speed range of 600 to 850 rpm. Specifically engineered for the demanding maritime operating environment, these engines ensure stable performance under prolonged heavy-load conditions. They fully comply with the International Maritime Organization’s Tier II emission standards. Achieving outstanding fuel efficiency across all operating conditions, they significantly reduce vessel operating costs. Simple routine maintenance effectively minimizes downtime, enhancing vessel availability.
General Specifications of LC8250ZLC Series
| Type: | In-line, four-stroke, direct-injection, turbocharged, intercooled, irreversible |
| Cylinders: | 8 |
| Cylinder Bore: | 250 mm |
| Piston Stroke: | 320 mm |
| Total Displacement : | 125.67 L |
| Rated Power: | 732-1960 kW |
| Rated Speed: | 600-850 rpm |
| Compression Ratio: | 12.5 |
| Dimensions (L×W×H): | 5250×1500×2990 (Reference only) |
| Weight: | 17900 kg |
| 1470 kW | LC8250ZLC | |||||||
| 1617 kW | LC8250ZLC-1 | |||||||
| 1765 kW | LC8250ZLC-2 | |||||||
| 882 kW | LC8250ZLC-3 | |||||||
| 1103 kW | LC8250ZLC-4 | |||||||
| 1177 kW | LC8250ZLC-5 | |||||||
| 1030 kW | LC8250ZLC-6 | |||||||
| 732 kW | LC8250ZLC-7 | |||||||
| 1213 kW | LC8250ZLC-8 | |||||||
| 1324 kW | LC8250ZLC-9 | |||||||
| 1030 kW | LC8250ZLC-10 | |||||||
| 1617 kW | LC8250ZLC-11 | |||||||
| 1960 kW | LC8250ZLC-15 | |||||||
Engine Model Rated Power/kW | 0 | 300 | 600 | 900 | 1200 | 1500 | 1800 | 2100 |
Engine Model | Rated Power | Rated Speed | Engine Model | Rated Power | Rated Speed | ||
| LC8250ZLC | 1470 kW | 750 rpm | LC8250ZLC-1 | 1617 kW | 825 rpm | ||
| LC8250ZLC-2 | 1765 kW | 825 rpm | LC8250ZLC-3 | 882 kW | 600 rpm | ||
| LC8250ZLC-4 | 1103 kW | 750 rpm | LC8250ZLC-5 | 1177 kW | 750 rpm | ||
| LC8250ZLC-6 | 1030 kW | 700 rpm | LC8250ZLC-7 | 732 kW | 650 rpm | ||
| LC8250ZLC-8 | 1213 kW | 750 rpm | LC8250ZLC-9 | 1324 kW | 750 rpm | ||
| LC8250ZLC-10 | 1030 kW | 600 rpm | LC8250ZLC-11 | 1617 kW | 750 rpm | ||
| LC8250ZLC-15 | 1960 kW | 850 rpm | |||||
| ——END—— | |||||||
Zichai LC8250ZLC Series Marine Engine
ZICHAI Marine LC8250ZLC Engine
Engine Model: LC8250ZLC
Rate Power: 1470 kW
Rate Speed: 750 rpm
ZICHAI Marine LC8250ZLC-1 Engine
Engine Model: LC8250ZLC-1
Rate Power: 1617 kW
Rate Speed: 825 rpm
ZICHAI Marine LC8250ZLC-2 Engine
Engine Model: LC8250ZLC-2
Rate Power: 1765 kW
Rate Speed: 825 rpm
ZICHAI Marine LC8250ZLC-3 Engine
Engine Model: LC8250ZLC-3
Rate Power: 882 kW
Rate Speed: 600 rpm
ZICHAI Marine LC8250ZLC-4 Engine
Engine Model: LC8250ZLC-4
Rate Power: 1103 kW
Rate Speed: 750 rpm
ZICHAI Marine LC8250ZLC-5 Engine
Engine Model: LC8250ZLC-5
Rate Power: 1177 kW
Rate Speed: 750 rpm
ZICHAI Marine LC8250ZLC-6 Engine
Engine Model: LC8250ZLC-6
Rate Power: 1030 kW
Rate Speed: 700 rpm
ZICHAI Marine LC8250ZLC-7 Engine
Engine Model: LC8250ZLC-7
Rate Power: 735 kW
Rate Speed: 650 rpm
ZICHAI Marine LC8250ZLC-8 Engine
Engine Model: LC8250ZLC-8
Rate Power: 1213 kW
Rate Speed: 750 rpm
ZICHAI Marine LC8250ZLC-9 Engine
Engine Model: LC8250ZLC-9
Rate Power: 1324 kW
Rate Speed: 750 rpm
ZICHAI Marine LC8250ZLC-10 Engine
Engine Model: LC8250ZLC-10
Rate Power: 1030 kW
Rate Speed: 600 rpm
ZICHAI Marine LC8250ZLC-11 Engine
Engine Model: LC8250ZLC-11
Rate Power: 1617 kW
Rate Speed: 750 rpm
ZICHAI Marine LC8250ZLC-15 Engine
Engine Model: LC8250ZLC-15
Rate Power: 1960 kW
Rate Speed: 850 rpm
