ZICHAI LC6250ZLC Series Marine Engine

The Zichai LC6250ZLC series marine diesel engines are developed based on decades of experience in marine propulsion R&D and manufacturing. Featuring a robust power core, these highly reliable products offer a power range of 1103 kW to 1470 kW and a speed range of 720 to 850 rpm. Specifically engineered for the demanding maritime operating environment, these engines ensure stable performance under prolonged heavy-load conditions. They fully comply with the International Maritime Organization’s Tier II emission standards. Achieving outstanding fuel efficiency across all operating conditions, they significantly reduce vessel operating costs. Simple routine maintenance effectively minimizes downtime, enhancing vessel availability.

coming soon…

coming soon…

coming soon…

General Specifications of LC6250ZLC Series

Type: In-line, four-stroke, direct-injection, turbocharged, intercooled, irreversible
Cylinders: 6
Cylinder Bore:
250 mm
Piston Stroke:
320 mm
Total Displacement : 94.25 L
Rated Power: 1103-1470 kW
Rated Speed: 720-850 rpm
Compression Ratio: 12.5
Dimensions (L×W×H): 4340×1500×2990 (Reference only)
Weight: 13500 kg



LC6250ZLC 1324 kW LC6250ZLC
LC6250ZLC-1 1103 kW LC6250ZLC-1
LC6250ZLC-2 1213 kW LC6250ZLC-2
LC6250ZLC-5 1103 kW LC6250ZLC-5
LC6250ZLC-7 1470 kW LC6250ZLC-7

Engine Model

Rated Power/kW

0 300 600 900 1200 1500 1800 2100
Zichai LC6250ZLC Series Catalogue

Engine Model

Rated Power

Rated Speed

Engine Model

Rated Power

Rated Speed

LC6250ZLC 1324 kW 825 rpm LC6250ZLC-1 1103 kW 750 rpm
LC6250ZLC-2 1213 kW 750 rpm LC6250ZLC-5 1103 kW 720 rpm
LC6250ZLC-7 1470 kW 850 rpm
——END——

Zichai LC6250ZLC Series Marine Engine

This is the list of all series of Zichai LC6250ZLC Series Marine Engine.
