ZICHAI Z6180ZLCZ Series Marine Engine

The Zichai Z6180ZLCZ series marine diesel engines are developed based on decades of experience in marine propulsion R&D and manufacturing. Featuring a robust power core, these highly reliable products offer a power range of 294 kW to 600 kW and a speed range of 1000 to 1500 rpm. Specifically engineered for the demanding maritime operating environment, these engines ensure stable performance under prolonged heavy-load conditions. They fully comply with the International Maritime Organization’s Tier II emission standards. Achieving outstanding fuel efficiency across all operating conditions, they significantly reduce vessel operating costs. Simple routine maintenance effectively minimizes downtime, enhancing vessel availability.

coming soon…

coming soon…

coming soon…

General Specifications of Z6180ZLCZ Series

Rated Power : 294-600 kW
Rated Speed : 1000-1500 rpm
Cylinder Bore :
180 mm
Piston Stroke :
210 mm
Cylinder No. : 6
Total Displacement : 32.06 L
Compression Ratio : 14.5
Minimum Stable Speed : 323-675 rpm
Mean Piston Speed : 7.00-10.50 m/s



Z6180ZLCZ-1 600 kW Z6180ZLCZ-1
Z6180ZLCZ-4 478 kW Z6180ZLCZ-4
Z6180ZLCZ-5B 560 kW Z6180ZLCZ-5B
Z6180ZLCZ-8 400 kW Z6180ZLCZ-8
Z6180ZLCZ-9B 500 kW Z6180ZLCZ-9B
Z6180ZLCZ-12 367 kW Z6180ZLCZ-12
Z6180ZLCZ-13A 440 kW Z6180ZLCZ-13A
Z6180ZLCZ-16 294 kW Z6180ZLCZ-16

Engine Model

Rated Power/kW

0 100 200 300 400 500 600 700
Zichai Z6180ZLCZ Series Catalogue

Engine Model

Rated Power

Rated Speed

Engine Model

Rated Power

Rated Speed

Z6180ZLCZ-1 600 kW 1500 rpm Z6180ZLCZ-4 478 kW 1500 rpm
Z6180ZLCZ-5B 560 kW 1350 rpm Z6180ZLCZ-8 400 kW 1350 rpm
Z6180ZLCZ-9B 500 kW 1200 rpm Z6180ZLCZ-12 367 kW 1200 rpm
Z6180ZLCZ-13A 440 kW 1000 rpm Z6180ZLCZ-16 294 kW 1000 rpm
——END——

Zichai Z6180ZLCZ Series Marine Engine

This is the list of all series of Zichai Z6180ZLCZ Series Marine Engine.
