ZICHAI ZC8200ZLD Series Generator Set
The Zichai ZC8200ZLD Series generator sets leverage the company’s decades of experience in marine power R&D and manufacturing. With diverse product types and fuel adaptability, these generator sets find extensive applications across industrial, energy, environmental, and infrastructure sectors. Featuring robust construction and reliable operation, the series covers a power range of 1100 kW to 1300 kW at speeds of 1000 rpm, ensuring stable and efficient performance under continuous load conditions. Compliant with international and domestic emission standards, this series achieves exceptional fuel efficiency under full load conditions, significantly reducing operational costs. Through optimized maintainability and durability design, these generator sets demonstrate exceptional availability and adaptability in real-world applications.
General Specifications of ZC8200ZLD Series
| Rated Power : | 1100 – 1300 kW |
| Maximum Power of Diesel Engine : | 1358 – 1617 kW |
| Rated Speed : | 1000 rpm |
| Rated Current : | 1984 – 2345 A |
| Stationary Voltage Regulation Ratio : | ±1% (single-player);±2.5% (parallel) |
| Fuel Consumption : | 190 g/kW·h |
| Lube Oil Consumption : | 0.9 g/kW·h |
| Weight of Set : | 23000 kg |
| Rated Frequency : | 50 Hz |
| 1100 kW | ZDMO1100PNOA | |||||||
| 1200 kW | ZDMO1200PNOA | |||||||
| 1300 kW | ZDMO1300PNOA | |||||||
Engine Model Rated Power/kW | 1050 | 1100 | 1150 | 1200 | 1250 | 1300 | 1350 | 1400 |
Engine Model | Rated Power | Rated Speed | Engine Model | Rated Power | Rated Speed | ||
| ZDMO1100PNOA | 1100 kw | 1000 rpm | ZDMO1200PNOA | 1200 kw | 1000 rpm | ||
| ZDMO1300PNOA | 1300 kw | 1000 rpm | |||||
| ——END—— | |||||||
Zichai ZC8200ZLD Series Generator Set
This is the list of all series of Zichai ZC8200ZLD Series Generator Set.
ZICHAI ZDMO1100PNOA Generator Set
Engine Model: ZC8200ZLD-2
Rate Power: 1100kW
Continuous Speed: 1000 rpm
ZICHAI ZDMO1200PNOA Generator Set
Engine Model: ZC8200ZLD-1
Rate Power: 1200kW
Continuous Speed: 1000 rpm
ZICHAI ZDMO1300PNOA Generator Set
Engine Model: ZC8200ZLD
Rate Power: 1300kW
Continuous Speed: 1000 rpm
