ZICHAI ZC8200ZLC Series Marine Engine
The Zichai ZC8200ZLC series marine diesel engines are developed based on decades of experience in marine propulsion R&D and manufacturing. Featuring a robust power core, these highly reliable products offer a power range of 1323 kW to 1470 kW and a speed range of 1000 rpm. Specifically engineered for the demanding maritime operating environment, these engines ensure stable performance under prolonged heavy-load conditions. They fully comply with the International Maritime Organization’s Tier II emission standards. Achieving outstanding fuel efficiency across all operating conditions, they significantly reduce vessel operating costs. Simple routine maintenance effectively minimizes downtime, enhancing vessel availability.
General Specifications of ZC8200ZLC Series
| Rated Power : | 1323-1470 kW |
| Rated Speed : | 1000 rpm |
| Cylinder Bore : | 200 mm |
| Piston Stroke : | 285 mm |
| Cylinder No. : | 8 |
| Total Displacement : | 71.63 L |
| Maximum Combustion Pressure : | 19.5 MPa |
| Fuel Oil Consumption : | 190 g/kW·h |
| Mean Piston Speed : | 9.5 m/s |
| 1470 kW | ZC8200ZLC | |||||||
| 1323 kW | ZC8200ZLC-1 | |||||||
Engine Model Rated Power/kW | 1000 | 1100 | 1200 | 1300 | 1400 | 1500 | 1600 | 1700 |
Engine Model | Rated Power | Rated Speed | Engine Model | Rated Power | Rated Speed | ||
| ZC8200ZLC | 1470 kW | 1000 rpm | ZC8200ZLC-1 | 1323 kW | 1000 rpm | ||
| ——END—— | |||||||
Zichai ZC8200ZLC Series Marine Engine
This is the list of all series of Zichai ZC8200ZLC Series Marine Engine.
ZICHAI Marine ZC8200ZLC Engine
Engine Model: ZC8200ZLC
Rate Power: 1470 kW
Rate Speed: 1000 rpm
ZICHAI Marine ZC8200ZLC-1 Engine
Engine Model: ZC8200ZLC-1
Rate Power: 1323 kW
Rate Speed: 1000 rpm
