ZICHAI Marine ZC8200ZLC-1 Engine

The ZC8200ZLC-1 is an 8-cylinder marine engine featuring an in-line, four-stroke, direct-injection, turbocharged and intercooled non-reversible design. With a cylinder bore of 200 mm, piston stroke of 285 mm, and rated speed of 1000 rpm, it delivers a rated power of 1323 kW, with an optimized fuel consumption rate of 190 g/kW·h. Built with robust construction and sophisticated engineering, it has been rigorously tested under harsh operating conditions to guarantee stable power output and greatly improve equipment uptime.

Supported by advanced combustion and electronic control systems, the engine achieves outstanding efficiency and energy conservation, effectively lowering fuel consumption and operating costs to enhance customer profitability. Furthermore, it fully meets the latest domestic and international emission requirements, embodying eco-friendly performance and supporting sustainable development in the shipping industry. With superior power, reliability and economy, it serves as an ideal power solution for various marine applications.

Advantages of Marine Engine ZC8200ZLC-1

  • Reliable & Durable: Sturdy structure and reliable operation ensure stable performance and long service life.

  • Highly Efficient: Advanced technology optimizes energy efficiency and lowers operating costs effectively.

  • Eco-friendly: Fully compliant with international emission regulations for green and sustainable operation.

  • Stable Output: Professional design guarantees consistent power performance and high uptime.

Technical Specifications

Engine Model : ZC8200ZLC-1
Rated Power : 1323 kW
Rated Speed : 1000 rpm
Cylinder Bore : 200 mm
Piston Stroke : 285 mm
Cylinder No. : 8
Mean Effective Pressure : 2.22 MPa
Mean Piston Speed : 9.5 m/s
Maximum Combustion Pressure : 19.5 MPa



coming soon…

coming soon…

coming soon…

Engine Model

Rated Power

Rated Speed

Mean Effective Pressure

ZC8200ZLC 1470 kW 1000 rpm 2.46 MPa
ZC8200ZLC-1 1323 kW 1000 rpm 2.22 MPa
——END——



General Information of ZICHAI ZC8200ZLC-1 Marine Engine
Model ZC8200ZLC-1 Type In-line, four strokes, direct injection,
turbocharged, intercooled, irreversible
Cylinder No. 8 Cylinder Bore / Piston Stroke 200 mm/ 285 mm
Total Displacement 71.63 L Rated Power / Speed 1323 kW / 1000 rpm
Overload Power / Speed 1455 kW / 1032 rpm Mean Piston Speed 9.5 m/s
Mean Effective Pressure 2.22 MPa Absolute Boosted Pressure 0.38±0.01 MPa
Maximum Combustion Pressure 19.5 MPa Fuel Oil Consumption 190 g/kW·h
Lubrication Oil Consumption 0.8 g/kW·h Rotation / Firing Order Viewed from flywheel side
Clockwise: 1-3-7-4-8-6-2-5
Starting Method Compressed air motor starting Lubricating Method Pressure lubrication
Height Of Lifting Piston 1655 mm Weight 12300 kg
Dimensions ( L × W × H )

3846×1453×2035 mm
(Only reference, please refer to the drawing)

——END——

coming soon…

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.

The picture of Sale Manual showing the accessories and scopes of supply.

Sale Manual

The picture of Installation Drawing showing the accessories and scopes of supply.

Installation Drawing

The picture of Installation Manual showing the accessories and scopes of supply.

Installation Manual

The picture of Operation Manual showing the accessories and scopes of supply.

Operation Manual

The picture of Engine Parts Catalogue showing the accessories and scopes of supply.

Parts Catalogue

The picture of Test Report and Certifcate showing the accessories and scopes of supply.

Report & Certifcate
