ZICHAI Z8170ZLD Series Generator Set
The Zichai Z8170ZLD Series generator sets leverage the company’s decades of experience in marine power R&D and manufacturing. With diverse product types and fuel adaptability, these generator sets find extensive applications across industrial, energy, environmental, and infrastructure sectors. Featuring robust construction and reliable operation, the series covers a power range of 280 kW to 500 kW at speeds of 1000 to 1500 rpm, ensuring stable and efficient performance under continuous load conditions. Compliant with international and domestic emission standards, this series achieves exceptional fuel efficiency under full load conditions, significantly reducing operational costs. Through optimized maintainability and durability design, these generator sets demonstrate exceptional availability and adaptability in real-world applications.
General Specifications of Z8170ZLD Series
| Rated Power : | 280 – 500 kW |
| Maximum Power of Diesel Engine : | 385 – 660 kW |
| Rated Speed : | 1000 – 1500 rpm |
| Rated Current : | 449 – 902 A |
| Stationary Voltage Regulation Ratio : | ±2.5% (parallel) |
| Fuel Consumption : | 196 g/kW·h |
| Lube Oil Consumption : | 1.0 g/kW·h |
| Weight of Set : | 6000 -7900 kg |
| Rated Frequency : | 50/60 Hz |
| 280 kW | ZDMO280PNOB | |||||||
| 300 kW | ZDMO300PNOA | |||||||
| 320 kW | ZDMO320PNOA | |||||||
| 320 kW | ZDMO320PNOB | |||||||
| 350 kW | ZDMO350PNOA | |||||||
| 400 kW | ZDMO400PNOA | |||||||
| 400 kW | ZDMO400PNOB | |||||||
| 450 kW | ZDMO450PNOB | |||||||
| 500 kW | ZDMO500PNOA | |||||||
Engine Model Rated Power/kW | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 550 |
Engine Model | Rated Power | Rated Speed | Engine Model | Rated Power | Rated Speed | ||
| ZDMO280PNOB | 280 kw | 1200 rpm | ZDMO300PNOA | 300 kw | 1000 rpm | ||
| ZDMO320PNOA | 320 kw | 1000 rpm | ZDMO320PNOB | 320 kw | 1200 rpm | ||
| ZDMO350PNOA | 350 kw | 1000 rpm | ZDMO400PNOA | 400 kw | 1000 rpm | ||
| ZDMO400PNOB | 400 kw | 1200 rpm | ZDMO450PNOB | 450 kw | 1200 rpm | ||
| ZDMO500PNOA | 500 kw | 1500 rpm | |||||
| ——END—— | |||||||
Zichai Z8170ZLD Series Generator Set
This is the list of all series of Zichai Z8170ZLD Series Generator Set.
ZICHAI ZDMO280PNOB Generator Set
Engine Model: Z8170ZLD-7
Rate Power: 280kW
Continuous Speed: 1200 rpm
ZICHAI ZDMO300PNOA Generator Set
Engine Model: Z8170ZLD-1
Rate Power: 300kW
Continuous Speed: 1000 rpm
ZICHAI ZDMO320PNOA Generator Set
Engine Model: Z8170ZLD-1
Rate Power: 320kW
Continuous Speed: 1000 rpm
ZICHAI ZDMO320PNOB Generator Set
Engine Model: Z8170ZLD-8
Rate Power: 320kW
Continuous Speed: 1200 rpm
ZICHAI ZDMO350PNOA Generator Set
Engine Model: Z8170ZLD
Rate Power: 350kW
Continuous Speed: 1000 rpm
ZICHAI ZDMO400PNOA Generator Set
Engine Model: Z8170ZLD
Rate Power: 400kW
Continuous Speed: 1000 rpm
ZICHAI ZDMO400PNOB Generator Set
Engine Model: Z8170ZLD-3
Rate Power: 400kW
Continuous Speed: 1200 rpm
ZICHAI ZDMO450PNOB Generator Set
Engine Model: Z8170ZLD-11
Rate Power: 450kW
Continuous Speed: 1200 rpm
ZICHAI ZDMO500PNOA Generator Set
Engine Model: Z8170ZLD-6
Rate Power: 500kW
Continuous Speed: 1500 rpm
