ZICHAI LB8250ZLD Series Generator Set
The Zichai LB8250ZLD Series generator sets leverage the company’s decades of experience in marine power R&D and manufacturing. With diverse product types and fuel adaptability, these generator sets find extensive applications across industrial, energy, environmental, and infrastructure sectors. Featuring robust construction and reliable operation, the series covers a power range of 1000 kW to 1250 kW at speeds of 750 rpm, ensuring stable and efficient performance under continuous load conditions. Compliant with international and domestic emission standards, this series achieves exceptional fuel efficiency under full load conditions, significantly reducing operational costs. Through optimized maintainability and durability design, these generator sets demonstrate exceptional availability and adaptability in real-world applications.
General Specifications of LB8250ZLD Series
| Rated Power : | 1000 – 1250 kW |
| Maximum Power of Diesel Engine : | 1213 – 1617 kW |
| Rated Speed : | 750 rpm |
| Rated Current : | 631 – 974 A |
| Stationary Voltage Regulation Ratio : | ±2.5% (parallel) |
| Fuel Consumption : | 198 g/kW·h |
| Lube Oil Consumption : | 1.0 g/kW·h |
| Weight of Set : | 32000 kg |
| Rated Frequency : | 50 Hz |
| 1000 kW | ZDMO1000PNOA | |||||||
| 1000 kW | ZDMO1000PNOA-I | |||||||
| 1050 kW | ZDMO1050PNOA | |||||||
| 1200 kW | ZDMO1200PNOA | |||||||
| 1250 kW | ZDMO1250PNOA | |||||||
Engine Model Rated Power/kW | 950 | 1000 | 1050 | 1100 | 1150 | 1200 | 1250 | 1300 |
Engine Model | Rated Power | Rated Speed | Engine Model | Rated Power | Rated Speed | ||
| ZDMO1000PNOA | 1000 kw | 750 rpm | ZDMO1000PNOA-I | 1000 kw | 750 rpm | ||
| ZDMO1050PNOA | 1050 kw | 750 rpm | ZDMO1200PNOA | 1200 kw | 750 rpm | ||
| ZDMO1250PNOA | 1250 kw | 750 rpm | |||||
| ——END—— | |||||||
Zichai LB8250ZLD Series Generator Set
This is the list of all series of Zichai LB8250ZLD Series Generator Set.
ZICHAI ZDMO1000PNOA Generator Set
Engine Model: LB8250ZLD
Rate Power: 1000kW
Continuous Speed: 750 rpm
ZICHAI ZDMO1000PNOA-I Generator Set
Engine Model: LB8250ZLD-1
Rate Power: 1000kW
Continuous Speed: 750 rpm
ZICHAI ZDMO1050PNOA Generator Set
Engine Model: LB8250ZLD-3
Rate Power: 1050kW
Continuous Speed: 750 rpm
ZICHAI ZDMO1200PNOA Generator Set
Engine Model: LB8250ZLD-4
Rate Power: 1200kW
Continuous Speed: 750 rpm
ZICHAI ZDMO1250PNOA Generator Set
Engine Model: LB8250ZLD-5
Rate Power: 1250kW
Continuous Speed: 750 rpm
