ZICHAI L6160ZLCZ Series Marine Engine

The Zichai L6160ZLCZ series marine diesel engines are developed based on decades of experience in marine propulsion R&D and manufacturing. Featuring a robust power core, these highly reliable products offer a power range of 100 kW to 441 kW and a speed range of 1000 to 1500 rpm. Specifically engineered for the demanding maritime operating environment, these engines ensure stable performance under prolonged heavy-load conditions. They fully comply with the International Maritime Organization’s Tier II emission standards. Achieving outstanding fuel efficiency across all operating conditions, they significantly reduce vessel operating costs. Simple routine maintenance effectively minimizes downtime, enhancing vessel availability.

coming soon…

coming soon…

coming soon…

General Specifications of L6160ZLCZ Series

Continuous Power: 100-441 kW / 136-600 HP
Continuous Speed: 1000-1500 rpm
Cylinder Bore: 160 mm
Piston Stroke: 200 mm
Cylinder No. : 6
Total Displacement: 24.13 L
Compression Ratio: 14.5
Minimum Steady Speed Under Load: 400-675 rpm
Mean Piston Speed: 0.50-1.46 m/s
L6160ZLCZ-1 441 kW L6160ZLCZ-1
L6160ZLCZ-17 397 kW L6160ZLCZ-17
L6160ZLCZ-29 300 kW L6160ZLCZ-29
L6160ZLCZ-48 300 kW L6160ZLCZ-48
L6160ZLCZ-66 200 kW L6160ZLCZ-66
L6160ZLCZ-96 200 kW L6160ZLCZ-96
L6160ZLCZ-112 147 kW L6160ZLCZ-6
L6160ZLCZ-127 100 kW L6160ZLCZ-127

Engine Model

Continuous Power/kW

0 100 200 300 400 500 600 700
Zichai L6160ZLCZ Series Catalogue

Engine Model

Continuous Power

Continuous Speed

Engine Model

Continuous Power

Continuous Speed

L6160ZLCZ-1 441 kW 1500 rpm L6160ZLCZ-17 397 kW 1350 rpm
L6160ZLCZ-29 300 kW 1350 rpm L6160ZLCZ-48 300 kW 1200 rpm
L6160ZLCZ-66 200 kW 1200 rpm L6160ZLCZ-96 200 kW 1000 rpm
L6160ZLCZ-112 147 kW 1000 rpm L6160ZLCZ-127 100 kW 1000 rpm
——END——

Zichai L6160ZLCZ Series Marine Engine

This is the list of all series of Zichai L6160ZLCZ Series Marine Engine.
