Zichai Marine L6160ZLCZ-29 Engine
ZICHAI L6160ZLCZ-29 is a high-performance 6-cylinder marine diesel engine, featuring a Continuous speed of 1350 rpm, a cylinder bore of 160 mm and a piston stroke of 200 mm, with a Continuous power of 300 kW to deliver strong and stable power output. Its robust structure and sophisticated design are rigorously tested under harsh marine conditions, ensuring reliable and durable operation and effectively improving equipment uptime, which can meet the demanding needs of various marine vessels.
This engine also integrates high efficiency, energy saving and environmental protection. Equipped with advanced 4-stroke direct injection, exhaust turbocharging and intercooling technologies, it optimizes fuel economy, reducing operating costs and enhancing profitability for users. Meanwhile, it fully complies with the latest domestic and international emission regulations, minimizing harmful emissions and promoting sustainable shipping. With comprehensive advantages, it is an ideal choice for high-performance marine power.
Advantages of Marine Engine L6160ZLCZ-29
Reliable & Durable: Sturdy structure and reliable operation ensure stable performance and long service life.
Highly Efficient: Advanced technology optimizes energy efficiency and lowers operating costs effectively.
Eco-friendly: Fully compliant with international emission regulations for green and sustainable operation.
Stable Output: Professional design guarantees consistent power performance and high uptime.
Technical Specifications
| Engine Model: | L6160ZLCZ-29 |
| Type: | In-line, four-stroke, direct-injection, turbocharged, intercooled, suspended main bearing |
| Cylinders: | 6 |
| Cylinder Bore / Piston Stroke: | 160 mm / 200 mm |
| Total Displacement : | 24.13 L |
| Compression Ratio: | 14.5 |
| Continuous Speed: | 1350 rpm |
| Continuous Power: | 300 kW / 408 HP |
| Minimum Steady Speed Under Load: | 540 rpm |
| Dimensions (L×W×H): | 2000×1156×1635 (Reference only) |
| Net Weight: | 2650 kg |
Engine Model | Continuous Power | Continuous Speed | Minimum Steady speed under load |
| L6160ZLC-1 | 441 kW | 1500 rpm | 675 rpm |
| L6160ZLC-17 | 397 kW | 1350 rpm | 540 rpm |
| L6160ZLC-29 | 300 kW | 1350 rpm | 540 rpm |
| L6160ZLC-48 | 300 kW | 1200 rpm | 480 rpm |
| L6160ZLC-66 | 200 kW | 1200 rpm | 480 rpm |
| L6160ZLC-96 | 200 kW | 1000 rpm | 400 rpm |
| L6160ZLC-112 | 147 kW | 1000 rpm | 400 rpm |
| L6160ZLC-127 | 100 kW | 1000 rpm | 400 rpm |
| ——END—— | |||
| General Information of ZICHAI L6160ZLCZ-29 Marine Engine | |||
|---|---|---|---|
| Model | L6160ZLCZ-29 | Type | In-line, four-stroke, direct-injection, turbocharged, intercooled, suspended main bearing |
| Cylinders | 6 | Cylinder Bore | 160 mm |
| Piston Stroke | 200 mm | Total Displacement | 24.13 L |
| Compression Ratio | 14.5 | Continuous Speed | 1350 rpm |
| Continuous Power | 300 kW | Minimum Steady speed under load | 540 rpm |
| Mean Piston Speed | 9.00 m/s | Mean Effective Pressure | 1.11 MPa |
| Fuel Oil Consumption | 189 g/(kW·h) | Lub. Oil Consumption | 0.5 g/(kW·h) |
| Rotation | Viewed from flywheel end: Counterclockwise | Fire Order | 1-5-3-6-2-4 |
| Starting Method | Air starting / Electric starting / Air & electric dual starting | Cooling Method | Closed water cooling |
| Lubrication Method | Pressure lubrication | Net Weight | 2650 kg |
| Dimensions (L×W×H) | 2000×1156×1635 mm (Reference only) | ||
| ——END—— | |||
ZICHAI L6160ZLCZ Series Marine Engine Dimensions
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
