ZICHAI Z6170ZLCZ Series Marine Engine

The Zichai Z6170ZLCZ series marine diesel engines are developed based on decades of experience in marine propulsion R&D and manufacturing. Featuring a robust power core, these highly reliable products offer a power range of 220 kW to 495 kW and a speed range of 1000 to 1500 rpm. Specifically engineered for the demanding maritime operating environment, these engines ensure stable performance under prolonged heavy-load conditions. They fully comply with the International Maritime Organization’s Tier II emission standards. Achieving outstanding fuel efficiency across all operating conditions, they significantly reduce vessel operating costs. Simple routine maintenance effectively minimizes downtime, enhancing vessel availability.

coming soon...

General Specifications of Z6170ZLCZ Series

Rated Power : 220-495 kW
Rated Speed : 1000-1500 rpm
Cylinder Bore :
170 mm
Piston Stroke :
200 mm
Cylinder No. : 6
Compression Ratio : 14.5
Minimum Stable Speed : 400-675 rpm
Mean Piston Speed : 6.67-10.00 m/s



Z6170ZLCZ 300 kW Z6170ZLCZ
Z6170ZLCZ-1 220 kW Z6170ZLCZ-1
Z6170ZLCZ-2 258 kW Z6170ZLCZ-2
Z6170ZLCZ-3 330 kW Z6170ZLCZ-3
Z6170ZLCZ-4 350 kW Z6170ZLCZ-4
Z6170ZLCZ-5 260 kW Z6170ZLCZ-5
Z6170ZLCZ-6 300 kW Z6170ZLCZ-6
Z6170ZLCZ-7 400 kW Z6170ZLCZ-7
Z6170ZLCZ-8 450 kW Z6170ZLCZ-8
Z6170ZLCZ-9 400 kW Z6170ZLCZ-9
Z6170ZLCZ-12 350 kW Z6170ZLCZ-12
Z6170ZLCZ-14 250 kW Z6170ZLCZ-14
Z6170ZLCZ-18 385 kW Z6170ZLCZ-18
Z6170ZLCZ-19 330 kW Z6170ZLCZ-19
Z6170ZLCZ-20 430 kW Z6170ZLCZ-20
Z6170ZLCZ-35 495 kW Z6170ZLCZ-35

Engine Model

Rated Power/kW

200 250 300 350 400 450 500 550
Zichai Z6170ZLCZ Series Catalogue

Engine Model

Rated Power

Rated Speed

Engine Model

Rated Power

Rated Speed

Z6170ZLCZ 300 kW 1000 rpm Z6170ZLCZ-1 220 kW 1000 rpm
Z6170ZLCZ-2 258 kW 1000 rpm Z6170ZLCZ-3 330 kW 1200 rpm
Z6170ZLCZ-4 350 kW 1200 rpm Z6170ZLCZ-5 260 kW 1200 rpm
Z6170ZLCZ-6 300 kW 1200 rpm Z6170ZLCZ-7 400 kW 1500 rpm
Z6170ZLCZ-8 450 kW 1500 rpm Z6170ZLCZ-9 400 kW 1350 rpm
Z6170ZLCZ-12 350 kW 1300 rpm Z6170ZLCZ-14 250 kW 1200 rpm
Z6170ZLCZ-18 385 kW 1200 rpm Z6170ZLCZ-19 330 kW 1000 rpm
Z6170ZLCZ-20 430 kW 1350 rpm Z6170ZLCZ-35 495 kW 1500 rpm
——END——

Zichai Z6170ZLCZ Series Marine Engine

This is the list of all series of Zichai Z6170ZLCZ Series Marine Engine.
