ZICHAI Z6170ZLD Series Generator Set
The Zichai Z6170ZLD Series generator sets leverage the company’s decades of experience in marine power R&D and manufacturing. With diverse product types and fuel adaptability, these generator sets find extensive applications across industrial, energy, environmental, and infrastructure sectors. Featuring robust construction and reliable operation, the series covers a power range of 200 kW to 400 kW at speeds of 1000 to 1500 rpm, ensuring stable and efficient performance under continuous load conditions. Compliant with international and domestic emission standards, this series achieves exceptional fuel efficiency under full load conditions, significantly reducing operational costs. Through optimized maintainability and durability design, these generator sets demonstrate exceptional availability and adaptability in real-world applications.
General Specifications of Z6170ZLD Series
| Rated Power : | 200 – 400 kW |
| Maximum Power of Diesel Engine : | 302 – 495 kW |
| Rated Speed : | 1000/1500 rpm |
| Rated Current : | 361 – 722 A |
| Stationary Voltage Regulation Ratio : | ±2.5% (parallel) |
| Fuel Consumption : | 196 g/kW·h |
| Lube Oil Consumption : | 1.0 g/kW·h |
| Weight of Set : | 5800 kg |
| Rated Frequency : | 50 Hz |
| 200 kW | ZDMO200PNOA | |||||||
| 220 kW | ZDMO220PNOA | |||||||
| 250 kW | ZDMO250PNOA | |||||||
| 280 kW | ZDMO280PNOA | |||||||
| 300 kW | ZDMO300PNOA | |||||||
| 350 kW | ZDMO350PNOA | |||||||
| 400 kW | ZDMO400PNOA | |||||||
Engine Model Rated Power/kW | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 |
Engine Model | Rated Power | Rated Speed | Engine Model | Rated Power | Rated Speed | ||
| ZDMO200PNOA | 200 kw | 1000 rpm | ZDMO220PNOA | 220 kw | 1000 rpm | ||
| ZDMO250PNOA | 250 kw | 1000 rpm | ZDMO280PNOA | 280 kw | 1000 rpm | ||
| ZDMO300PNOA | 300 kw | 1000 rpm | ZDMO350PNOA | 350 kw | 1500 rpm | ||
| ZDMO400PNOA | 400 kw | 1500 rpm | |||||
| ——END—— | |||||||
Zichai Z6170ZLD Series Generator Set
This is the list of all series of Zichai Z6170ZLD Series Generator Set.
ZICHAI ZDMO200PNOA Generator Set
Engine Model: Z6170ZLD-2
Rate Power: 200kW
Continuous Speed: 1000 rpm
ZICHAI ZDMO220PNOA Generator Set
Engine Model: Z6170ZLD-2
Rate Power: 220kW
Continuous Speed: 1000 rpm
ZICHAI ZDMO250PNOA Generator Set
Engine Model: Z6170ZLD-1
Rate Power: 250kW
Continuous Speed: 1000 rpm
ZICHAI ZDMO280PNOA Generator Set
Engine Model: Z6170ZLD
Rate Power: 280kW
Continuous Speed: 1000 rpm
ZICHAI ZDMO300PNOA Generator Set
Engine Model: Z6170ZLD
Rate Power: 300kW
Continuous Speed: 1000 rpm
ZICHAI ZDMO350PNOA Generator Set
Engine Model: Z6170ZLD-10
Rate Power: 350kW
Continuous Speed: 1500 rpm
ZICHAI ZDMO400PNOA Generator Set
Engine Model: Z6170ZLD-6
Rate Power: 400kW
Continuous Speed: 1500 rpm
