ZICHAI L8230ZLC Series Marine Engine
The Zichai L8230ZLC series marine diesel engines are developed based on decades of experience in marine propulsion R&D and manufacturing. Featuring a robust power core, these highly reliable products offer a power range of 1176 kW to 1617 kW and a speed range of 1000 rpm. Specifically engineered for the demanding maritime operating environment, these engines ensure stable performance under prolonged heavy-load conditions. They fully comply with the International Maritime Organization’s Tier II emission standards. Achieving outstanding fuel efficiency across all operating conditions, they significantly reduce vessel operating costs. Simple routine maintenance effectively minimizes downtime, enhancing vessel availability.
General Specifications of L8230ZLC Series
| Type: | In-line, four-stroke, direct-injection, turbocharged, intercooled, irreversible |
| Cylinders: | 8 |
| Cylinder Bore: | 225 mm |
| Piston Stroke: | 290 mm |
| Total Displacement : | 92.24 L |
| Continuous Power: | 1176-1617 kW |
| Continuous Speed: | 1000 rpm |
| Dimensions (L×W×H): | 4105×1208×2526 (Reference only) |
| Weight: | 12500 kg |
| 1470 kW | L8230ZLC-1 | |||||||
| 1333 kW | L8230ZLC-2 | |||||||
| 1324 kW | L8230ZLC-3 | |||||||
| 1267 kW | L8230ZLC-4 | |||||||
| 1176 kW | L8230ZLC-5 | |||||||
| 1617 kW | L8230ZLC-10 | |||||||
Engine Model Continuous Power/kW | 0 | 300 | 600 | 900 | 1200 | 1500 | 1800 | 2100 |
Engine Model | Continuous Power | Continuous Speed | Engine Model | Continuous Power | Continuous Speed | ||
| L8230ZLC-1 | 1470 kW | 1000 rpm | L8230ZLC-2 | 1333 kW | 1000 rpm | ||
| L8230ZLC-3 | 1324 kW | 1000 rpm | L8230ZLC-4 | 1267 kW | 1000 rpm | ||
| L8230ZLC-5 | 1176 kW | 1000 rpm | L8230ZLC-10 | 1617 kW | 1000 rpm | ||
| ——END—— | |||||||
Zichai L8230ZLC Series Marine Engine
This is the list of all series of Zichai L8230ZLC Series Marine Engine.
Zichai Marine L8230ZLC-1 Engine
Engine Model: L8230ZLC-1
Continuous Power: 1470 kW
Continuous Speed: 1000 rpm
Zichai Marine L8230ZLC-2 Engine
Engine Model: L8230ZLC-2
Continuous Power: 1333 kW
Continuous Speed: 1000 rpm
Zichai Marine L8230ZLC-3 Engine
Engine Model: L8230ZLC-3
Continuous Power: 1324 kW
Continuous Speed: 1000 rpm
Zichai Marine L8230ZLC-4 Engine
Engine Model: L8230ZLC-4
Continuous Power: 1267 kW
Continuous Speed: 1000 rpm
Zichai Marine L8230ZLC-5 Engine
Engine Model: L8230ZLC-5
Continuous Power: 1176 kW
Continuous Speed: 1000 rpm
Zichai Marine L8230ZLC-10 Engine
Engine Model: L8230ZLC-10
Continuous Power: 1617 kW
Continuous Speed: 1000 rpm
