ZICHAI Marine 6N280ZLC Engine

The 6N280ZLC is a high-performance 6-cylinder marine engine, featuring a rated speed of 750 rpm, a cylinder bore of 280 mm and a piston stroke of 410 mm, with a rated power of 1470 kW (2000 PS) to deliver strong and stable power output. Its robust structure and sophisticated design are rigorously tested under harsh marine conditions, ensuring reliable and durable operation and effectively improving equipment uptime, which can meet the demanding needs of various marine vessels.

This engine also integrates high efficiency, energy saving and environmental protection. Equipped with advanced combustion and electronic control technologies, it optimizes fuel economy, reduces operating costs and enhances profitability for users. Meanwhile, it fully complies with the latest domestic and international emission regulations, minimizing harmful emissions and promoting sustainable shipping. With comprehensive advantages, it is an ideal choice for high-performance marine power.

Advantages of Marine Engine 6N280ZLC

  • Reliable & Durable: Sturdy structure and reliable operation ensure stable performance and long service life.

  • Highly Efficient: Advanced technology optimizes energy efficiency and lowers operating costs effectively.

  • Eco-friendly: Fully compliant with international emission regulations for green and sustainable operation.

  • Stable Output: Professional design guarantees consistent power performance and high uptime.

Technical Specifications

Engine Model : 6N280ZLC
Cylinder No. : 6
Cylinder Bore / Piston Stroke : 280 mm / 410 mm
Rated Speed : 750 rpm
Rated Power : 1470 kW / 2000 PS
Supercharge Pressure : 0.25 ± 0.02 MPa
Maximum Explosion Pressure : ≤18 MPa
Mean Effective Pressure : 1.55 MPa
Mean Piston Speed : 10.25 m/s



coming soon…

coming soon…

coming soon…

Engine Model

Rated Power

Rated Speed

Supercharging Pressure

6N280ZLC 1470 kW / 2000 PS 750 rpm 0.25 ± 0.02 MPa
6N280ZLC-1 1617 kW / 2200 PS 750 rpm 0.26 ± 0.02 MPa
6N280ZLC-2 1765 kW / 2400 PS 750 rpm 0.27 ± 0.02 MPa
6N280ZLC-3 1912 kW / 2600 PS 750 rpm 0.28 ± 0.02 MPa
6N280ZLC-4 2000 kW / 2720 PS 750 rpm 0.30 ± 0.02 MPa
6N280ZLC-5 2060 kW / 2800 PS 750 rpm 0.30 ± 0.02 MPa
6N280ZLC-6 2207 kW /3000 PS 750 rpm 0.32 ± 0.02 MPa
6N280ZLC-7 2354 kW / 3200 PS 750 rpm 0.34 ± 0.02 MPa
6N280ZLC-8 1765 kW / 2400 PS 800 rpm 0.26 ± 0.02 MPa
6N280ZLC-9 1912 kW / 2600 PS 800 rpm 0.27 ± 0.02 MPa
6N280ZLC-10 2000 kW / 2720 PS 800 rpm 0.28 ± 0.02 MPa
6N280ZLC-11 2060 kW / 2800 PS 800 rpm 0.28 ± 0.02 MPa
6N280ZLC-12 2207 kW / 3000 PS 800 rpm 0.30 ± 0.02 MPa
6N280ZLC-13 2354 kW / 3200 PS 800 rpm 0.32 ± 0.02 MPa
6N280ZLC-14 2500 kW / 3400 PS 800 rpm 0.33 ± 0.02 MPa
6N280ZLC-15 2647 kW / 3600 PS 800 rpm 0.34 ± 0.02 MPa
6N280ZLC-20 2200 kW / 2992 PS 800 rpm 0.30 ± 0.02 MPa
6N280ZLC-21 2450 kW / 3332 PS 800 rpm 0.32 ± 0.02 MPa
6N280ZLC-22 2426 kW / 3300 PS 800 rpm 0.32 ± 0.02 MPa
6N280ZLC-23 2574 kW / 3500 PS 800 rpm 0.34 ± 0.02 MPa
6N280ZLC-24 2720 kW / 3700 PS 825 rpm 0.34 ± 0.02 MPa
6N280ZLC-25 2760 kW / 3750 PS 825 rpm 0.36 ± 0.02 MPa
6N280ZLC-30 2942 kW / 4000 PS 825 rpm 0.36 ± 0.02 MPa
——END——



General Information of ZICHAI 6N280ZLC Marine Engine
Model 6N280ZLC No. Of Cylinders 6
Cylinder Bore/ Piston Stroke 280 mm / 410 mm Rated Speed 750 rpm
Rated Power 1470 kW / 2000 PS Supercharging Pressure 0.25 ± 0.02 MPa
Maximum Explosion Pressure ≤18 MPa Mean Effective Pressure 1.55 MPa
Mean Piston Speed 10.25 m/s Fuel Oil Consumption 188 (MCR) g/kW·h, 182 (75% MCR) g/kW·h
Lube Oil Consumption ≤0.8 g/kW·h Dimensions(L×W×H) 5102×2317×3660 mm
(Only reference, please refer to the drawing)
Weight 32000 kg
——END——

coming soon…

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
