ZICHAI Marine 8N280ZLC-15 Engine
The 8N280ZLC-15 is a high-performance 8-cylinder marine engine, featuring a rated speed of 800 rpm, a cylinder bore of 280 mm and a piston stroke of 410 mm, with a rated power of 3530 kW (4800 PS) to deliver strong and stable power output. Its robust structure and sophisticated design are rigorously tested under harsh marine conditions, ensuring reliable and durable operation and effectively improving equipment uptime, which can meet the demanding needs of various marine vessels.
This engine also integrates high efficiency, energy saving and environmental protection. Equipped with advanced combustion and electronic control technologies, it optimizes fuel economy, reduces operating costs and enhances profitability for users. Meanwhile, it fully complies with the latest domestic and international emission regulations, minimizing harmful emissions and promoting sustainable shipping. With comprehensive advantages, it is an ideal choice for high-performance marine power.
Advantages of Marine Engine 8N280ZLC-15
Reliable & Durable: Sturdy structure and reliable operation ensure stable performance and long service life.
Highly Efficient: Advanced technology optimizes energy efficiency and lowers operating costs effectively.
Eco-friendly: Fully compliant with international emission regulations for green and sustainable operation.
Stable Output: Professional design guarantees consistent power performance and high uptime.
Technical Specifications
| Engine Model : | 8N280ZLC-15 |
| Cylinder No. : | 8 |
| Cylinder Bore / Piston Stroke : | 280 mm / 410 mm |
| Rated Speed : | 800 rpm |
| Rated Power : | 3530 kW / 4800 PS |
| Supercharge Pressure : | 0.34 ± 0.02 MPa |
| Maximum Explosion Pressure : | ≤21 MPa |
| Mean Effective Pressure : | 2.62 MPa |
| Mean Piston Speed : | 10.933 m/s |
Engine Model | Rated Power | Rated Speed | Supercharging Pressure | ||
| 8N280ZLC | 2060 kW / 2800 PS | 750 rpm | 0.25 ± 0.02 MPa | ||
| 8N280ZLC-1 | 2207 kW / 3000 PS | 750 rpm | 0.26 ± 0.02 MPa | ||
| 8N280ZLC-2 | 2354 kW / 3200 PS | 750 rpm | 0.27 ± 0.02 MPa | ||
| 8N280ZLC-3 | 2500 kW / 3400 PS | 750 rpm | 0.28 ± 0.02 MPa | ||
| 8N280ZLC-4 | 2647 kW / 3600 PS | 750 rpm | 0.30 ± 0.02 MPa | ||
| 8N280ZLC-5 | 2795 kW / 3800 PS | 750 rpm | 0.30 ± 0.02 MPa | ||
| 8N280ZLC-6 | 2942 kW /4000 PS | 750 rpm | 0.32 ± 0.02 MPa | ||
| 8N280ZLC-7 | 3090 kW / 4200 PS | 750 rpm | 0.33 ± 0.02 MPa | ||
| 8N280ZLC-8 | 2207 kW / 3000 PS | 800 rpm | 0.25 ± 0.02 MPa | ||
| 8N280ZLC-9 | 2354 kW / 3200 PS | 800 rpm | 0.26 ± 0.02 MPa | ||
| 8N280ZLC-10 | 2500 kW / 3400 PS | 800 rpm | 0.27 ± 0.02 MPa | ||
| 8N280ZLC-11 | 2720 kW / 3700 PS | 800 rpm | 0.28 ± 0.02 MPa | ||
| 8N280ZLC-12 | 2942 kW / 4000 PS | 800 rpm | 0.30 ± 0.02 MPa | ||
| 8N280ZLC-13 | 3090 kW / 4200 PS | 800 rpm | 0.31 ± 0.02 MPa | ||
| 8N280ZLC-14 | 3310 kW / 4500 PS | 800 rpm | 0.33 ± 0.02 MPa | ||
| 8N280ZLC-15 | 3530 kW / 4800 PS | 800 rpm | 0.34 ± 0.02 MPa | ||
| 8N280ZLC-24 | 3600 kW / 4896 PS | 825 rpm | 0.35 ± 0.02 MPa | ||
| 8N280ZLC-25 | 3676 kW / 5000 PS | 825 rpm | 0.36 ± 0.02 MPa | ||
| 8N280ZLC-26 | 2980 kW / 4050 PS | 750 rpm | 0.32 ± 0.02 MPa | ||
| 8N280ZLC-27 | 3015 kW / 4100 PS | 750 rpm | 0.32 ± 0.02 MPa | ||
| 8N280ZLC-28 | 3052 kW / 4150 PS | 750 rpm | 0.33 ± 0.02 MPa | ||
| ——END—— | |||||
| General Information of ZICHAI 8N280ZLC-15 Marine Engine | |||||
|---|---|---|---|---|---|
| Model | 8N280ZLC-15 | No. Of Cylinders | 8 | ||
| Cylinder Bore/ Piston Stroke | 280 mm / 410 mm | Rated Speed | 800 rpm | ||
| Rated Power | 3530 kW / 4800 PS | Supercharging Pressure | 0.34 ± 0.02 MPa | ||
| Maximum Explosion Pressure | ≤21 MPa | Mean Effective Pressure | 2.62 MPa | ||
| Mean Piston Speed | 10.933 m/s | Fuel Oil Consumption | 188 (MCR) g/kW·h, 182 (75% MCR) g/kW·h | ||
| Lube Oil Consumption | ≤0.8 g/kW·h | Dimensions(L×W×H) | 5992×2240×3822.5 mm (Only reference, please refer to the drawing) | ||
| Weight | 38000 kg | ||||
| ——END—— | |||||
8N280ZLC Series Marine Engine Dimensions
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
