Zichai Marine L6230AZLC-3 Engine
Zichai L6230AZLC-3 is a high-performance 6-cylinder marine diesel engine, featuring a continuous speed of 1000 rpm, a cylinder bore of 225 mm and a piston stroke of 300 mm, with a continuous power of 1213 kW to deliver strong and stable power output. Its robust structure and sophisticated design are rigorously tested under harsh marine conditions, ensuring reliable and durable operation and effectively improving equipment uptime, which can meet the demanding needs of various marine vessels.
This engine also integrates high efficiency, energy saving and environmental protection. Equipped with advanced four-stroke direct injection, turbocharging and intercooling technologies, it optimizes fuel economy, reducing operating costs and enhancing profitability for users. Meanwhile, it fully complies with the latest domestic and international emission regulations, minimizing harmful emissions and promoting sustainable shipping. With comprehensive advantages, it is an ideal choice for high-performance marine power.
Advantages of Marine Engine L6230AZLC-3
Reliable & Durable: Sturdy structure and reliable operation ensure stable performance and long service life.
Highly Efficient: Advanced technology optimizes energy efficiency and lowers operating costs effectively.
Eco-friendly: Fully compliant with international emission regulations for green and sustainable operation.
Stable Output: Professional design guarantees consistent power performance and high uptime.
Technical Specifications
| Engine Model: | L6230AZLC-3 |
| Type: | In-line, four-stroke, direct-injection, turbocharged, intercooled, irreversible |
| Cylinders: | 6 |
| Cylinder Bore / Piston Stroke: | 225 mm / 300 mm |
| Total Displacement : | 71.57 L |
| Rated Speed: | 1000 rpm |
| Rated Power: | 1213 kW |
| One hour power: | 1334 kW |
| Minimum stable speed: | 400 rpm |
| Dimensions (L×W×H): | 3315×1145×2452 (Reference only) |
| Weight: | <10000 kg |
Engine Model | Rated Power | Rated Speed | One hour power |
| L6230AZLC-1 | 1470 kW | 1000 rpm | 1617 kW |
| L6230AZLC-2 | 1324 kW | 1000 rpm | 1457 kW |
| L6230AZLC-3 | 1213 kW | 1000 rpm | 1334 kW |
| ——END—— | |||
| General Information of ZICHAI L6230AZLC-3 Marine Engine | |||
|---|---|---|---|
| Model | L6230AZLC-3 | Type | In-line, four-stroke, direct-injection, turbocharged, intercooled, irreversible |
| Cylinders | 6 | Cylinder Bore | 225 mm |
| Piston Stroke | 300 mm | Total Displacement | 71.57 L |
| Compression ratio | 15 | Rated Speed | 1000 rpm |
| Rated Power | 1213 kW | One hour power | 1334 kW |
| Minimum stable speed | 400 rpm | Mean Piston Speed | 10 m/s |
| Mean Effective Pressure | 2.034 MPa | Supercharging pressure | 0.39±0.01 |
| Maximum explosion pressure | ≤18.0 | Exhaust temperature per cylinder | ≤450℃ |
| Exhaust temperature before turbocharger | <550℃ | Fuel Oil Consumption | 185 g/(kW·h) |
| Lub. Oil Consumption | 0.60 g/(kW·h) | Rotation | Viewed from the flywheel end:turn right is clockwise; turn left is counterclockwise |
| Firing order | Clockwise:1-4-2-6-5-3 | Starting Method | Compressed air starting motor |
| Starting air pressure | Air bottle pressure: 3.0 MPa; Pressure after reducing valve: 0.8 MPa | Dimensions (L×W×H) | 3315×1145×2452 mm (Reference only) |
| Height of lifting piston | 1780 mm | Weight | <10000 kg |
| ——END—— | |||
Coming soon
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
