ZICHAI ZDMO2600PNOB Generator Set
The ZDMO2600PNOB is a high-power, high-reliability diesel generator set, specifically engineered for large vessel propulsion, heavy industrial operations, and emergency power supply scenarios. Built on mature low-speed diesel engine technology and advanced power generation control systems, it delivers efficient and stable power output, providing users with long-lasting, dependable energy solutions.
Advantages of Generator Set ZDMO2600PNOB
Delivers a rated power of 2600 kW and standby power of 2882 kW, paired with the 8N260ZLD-20 diesel engine (2900 kW continuous power) at 720 rpm, reliably meeting heavy industrial and marine high-load demands.
Optimized combustion design achieves a fuel consumption rate of only 188 g/kW·h and a lube oil consumption rate of 0.9 g/kW·h, significantly cutting long-term operating costs while ensuring efficient performance.
Features automatic voltage regulation and a brushless self-excited system, with voltage regulation ratios of ±2.5% (single unit) and ±2.5% (parallel operation), maintaining stable 60 Hz output ideal for sensitive industrial and marine systems.
Rugged construction withstands harsh marine and industrial environments, supporting startup methods (compressed air) for seamless integration into diverse power networks.
Technical Specifications
| Generator Model: | ZDMO2600PNOB |
| Engine Model: | 6N280AZLD-20 |
| Rated Power: | 2600 kW |
| Continuous Speed: | 720 rpm |
| Fuel Consumption Rate: | 188 g/kW·h |
| Paralleling Capability: | Supported, voltage regulation ±2.5% |
| Cylinder Bore: | 280mm |
| Rated Frequency: | 60 Hz |
| lubrication Consumption: | 0.9 g/kW·h |
| Cylinder No.: | 8 |
| Starting Air Pressure: | 3MPa |
Generator Model | Rated Power | Engine Model | Rated Speed | Fuel Consumption |
| ZDMO2500PNOB | 2500kW @720 rpm | 8N280ZLD-19 | 720 rpm | 188g/kW·h |
| ZDMO2600PNOB | 2600kW @720 rpm | 8N280ZLD-20 | 720 rpm | 188g/kW·h |
| ZDMO2700PNOB | 2700kW @720 rpm | 8N280ZLD-21 | 720 rpm | 188g/kW·h |
| ——END—— | ||||
| General Information of ZICHAI ZDMO2600PNOB Generator Set | |||
| Rated Power | 2600 kW | Stand-by Power | 2882 kW |
| Rated Frequency | 60 Hz | Rated Power Factor (cos φ) | 0.8 Lagging |
| Stationary Voltage Regulation Ratio | ±2.5% | Adopted Diesel Engine Type | 6N280ZLD-20 |
| Continuous Power of Diesel Engine | 2900 kW | Maximum Power of Diesel Engine | 3190 kW |
| Rated Speed of Diesel Engine | 720 rpm | Fuel Consumption | 188 g/kW·h |
| Lube Oil Consumption | 0.9 g/kW·h | Cylinder No. | 8 |
| Cylinder Bore | 280 mm | Starting Mode | Compressed air |
| Starting Air Pressure | 3 MPa | ||
| ——END—— | |||
coming soon
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
