ZICHAI ZDMO3000PNOA Generator Set

The ZDMO3000PNOA is a high-power, high-reliability diesel generator set, specifically engineered for large vessel propulsion, heavy industrial operations, and emergency power supply scenarios. Built on mature low-speed diesel engine technology and advanced power generation control systems, it delivers efficient and stable power output, providing users with long-lasting, dependable energy solutions.
The code Z in the model name indicates that the engine brand of the unit is ZICHAI, the code D in the model name indicates that the fuel type is diesel, the code M in the model name indicates that the Marine-used, the code O in the model name indicates that the open type, the code 3000 in the model name indicates that the power is 3000KW, and the code P in the model name indicates that the power type is the primary power. The code N in the model name indicates that the generator brand is SinoGen, the code O in the model name indicates that the generator set has no ATS and no parallel function, and the code A in the model name indicates that the frequency of the generator set is 50hz.
As official exporting agent of ZICHAI, SinoGen is a professional power system solution provider, we provide one-stop power system solutions for customer from all over the world, from power system design to power system supply, from installation to commissioning, from after-sales services support to parts supply, SinoGen is your reliable power system partner that give you best value for money and reliable system solution.

Advantages of Generator Set ZDMO3000PNOA

Delivers a rated power of 3000 kW and standby power of 3300 kW, paired with the 8N280ZLD-10 diesel engine (3220 kW continuous power) at 750 rpm, reliably meeting heavy industrial and marine high-load demands.
Optimized combustion design achieves a fuel consumption rate of only 188 g/kW·h and a lube oil consumption rate of 0.9 g/kW·h, significantly cutting long-term operating costs while ensuring efficient performance.
Features automatic voltage regulation and a brushless self-excited system, with voltage regulation ratios of ±2.5% (single unit) and ±2.5% (parallel operation), maintaining stable 50 Hz output ideal for sensitive industrial and marine systems.
Rugged construction withstands harsh marine and industrial environments, supporting startup methods (compressed air) for seamless integration into diverse power networks.

Technical Specifications

Generator Model:	ZDMO3000PNOA
Engine Model:	8N280ZLD-10
Rated Power:	3000 kW
Continuous Speed:	750 rpm
Fuel Consumption Rate:	188 g/kW·h
Paralleling Capability:	Supported, voltage regulation ±2.5%
Cylinder Bore:	280mm
Rated Frequency:	50 Hz
lubrication Consumption:	0.9 g/kW·h
Cylinder No.:	8
Starting Air Pressure:	3MPa

coming soon

Generator Model	Rated Power	Engine Model	Rated Speed	Fuel Consumption
ZDMO2200PNOA	2200kW @750 rpm	8N280ZLD-3	750 rpm	188g/kW·h
ZDMO2200PNOB	2200kW @720 rpm	8N280ZLD-16	720 rpm	188g/kW·h
ZDMO2300PNOA	2300kW @750 rpm	8N280ZLD-4	750 rpm	188g/kW·h
ZDMO2300PNOB	2300kW @720 rpm	8N280ZLD-17	720 rpm	188g/kW·h
ZDMO2400PNOA	2400kW @750 rpm	8N280ZLD-5	750 rpm	188g/kW·h
ZDMO2400PNOB	2400kW @720 rpm	8N280ZLD-18	720 rpm	188g/kW·h
ZDMO2500PNOA	2500kW @750 rpm	8N280ZLD-6	750 rpm	188g/kW·h
ZDMO2600PNOA	2600kW @750 rpm	8N280ZLD-7	750 rpm	188g/kW·h
ZDMO2700PNOA	2700kW @750 rpm	8N280ZLD-8	750 rpm	188g/kW·h
ZDMO2800PNOA	2800kW @750 rpm	8N280ZLD-9	750 rpm	188g/kW·h
ZDMO3000PNOA	3000kW @750 rpm	8N280ZLD-10	750 rpm	188g/kW·h
——END——

General Infomation of Zichai ZDMO3000PNOA Generator Set
Rated Power	3000 kW	Stand-by Power	3300 kW
Rated Frequency	50 Hz	Rated Power Factor (cos φ)	0.8 Lagging
Stationary Voltage Regulation Ratio	±2.5%	Adopted Diesel Engine Type	8N280ZLD-10
Continuous Power of Diesel Engine	3220 kW	Maximum Power of Diesel Engine	3542 kW
Rated Speed of Diesel Engine	750 r/min	Fuel Consumption	188 g/kW·h
Lube Oil Consumption	0.9 g/kW·h	Cylinder No.	8
Cylinder Bore	280 mm	Starting Mode	Compressed air
Starting Air Pressure	3 MPa
