ZICHAI Marine ZC8270ZLC Engine

The ZC8270ZLC is an 8-cylinder marine engine featuring an in-line, four-stroke, direct-injection, turbocharged and intercooled non-reversible design. With a cylinder bore of 270 mm, piston stroke of 385 mm, total displacement of 176.3 L, and rated speed of 800 rpm, it delivers a rated power of 2560 kW / 3480 PS, with an optimized fuel consumption rate of 185 g/kW·h. Built with robust construction and sophisticated engineering, it has been rigorously tested under harsh operating conditions to guarantee stable power output and greatly improve equipment uptime.

Supported by advanced combustion and electronic control systems, the engine achieves outstanding efficiency and energy conservation, effectively lowering fuel consumption and operating costs to enhance customer profitability. Furthermore, it fully meets the latest domestic and international emission requirements, embodying eco-friendly performance and supporting sustainable development in the shipping industry. With superior power, reliability and economy, it serves as an ideal power solution for various marine applications.

Advantages of Marine Engine ZC8270ZLC

  • Reliable & Durable: Sturdy structure and reliable operation ensure stable performance and long service life.

  • Highly Efficient: Advanced technology optimizes energy efficiency and lowers operating costs effectively.

  • Eco-friendly: Fully compliant with international emission regulations for green and sustainable operation.

  • Stable Output: Professional design guarantees consistent power performance and high uptime.

Technical Specifications

Engine Model : ZC8270ZLC
Rated Power : 2560 kW / 3480 PS
Rated Speed : 800 rpm
Cylinder Bore : 270 mm
Piston Stroke : 385 mm
Cylinder No. : 8
Total Displacement : 176.3 L
Mean Effective Pressure : 2.18 MPa
Supercharge Pressure (Absolute) : 0.41 ± 0.01 MPa
Maximum Combustion Pressure : ≤19.5 MPa



coming soon…

coming soon…

coming soon…

Engine Model

Rated Power

Rated Speed

Mean Effective Pressure

ZC8270ZLC 2560 kW / 3480 PS 800 rpm 2.18 MPa
ZC8270ZLC-1 2400 kW / 3264 PS 750 rpm 2.18 MPa
ZC8270ZLC-2 2205 kW / 3000 PS 750 rpm 2.0 MPa
ZC8270ZLC-3 2060 kW / 2800 PS 750 rpm 1.87 MPa
ZC8270ZLC-4 2920 kW / 3970 PS 800 rpm 2.48 MPa
ZC8270ZLC-5 2720 kW / 3700 PS 800 rpm 2.31 MPa
ZC8270ZLC-6 1920 kW / 2610 PS 750 rpm 1.74 MPa
ZC8270ZLC-7 1800 kW /2450 PS 750 rpm 1.63 MPa
ZC8270ZLC-8 1620 kW / 2200 PS 750 rpm 1.47 MPa
ZC8270ZLC-9 1470 kW / 2000 PS 750 rpm 1.33 MPa
ZC8270ZLC-10 2650 kW / 3604 PS 750 rpm 2.40 MPa
ZC8270ZLC-11 2450 kW / 3000 PS 700 rpm 2.36 MPa
——END——
General Information of ZICHAI ZC8270ZLC Marine Engine
Model ZC8270ZLC Type In-line, four strokes, direct injection,
turbocharged, intercooled, irreversible
Rated Power 2560 kW / 3480 PS Rated Speed 800 rpm
Cylinder Bore 270 mm Piston Stroke 385 mm
Cylinder No. 8 Total Displacement 176.3 L
Compression Ratio 16.5 Minimum Stable Speed 320 rpm
Mean Piston Speed 10.267 m/s Mean Effective Pressure 2.18 MPa
Supercharger Pressure (Absolute) 0.41 ± 0.01 MPa Maximum Combustion Pressure ≤19.5 MPa
Each Cylinder Exhaust Temperature 280~340 ℃ Exhaust Temperature Before Turbocharger 480~530 ℃
Fuel Oil Consumption 185 g/kW·h Lubrication Oil Consumption 0.8 g/kW·h
Fire Order 1-2-4-6-8-7-5-3 (Clockwise)
1-3-5-7-8-6-4-2 (Counter-Clockwise)
Starting Method Compressed air starting motor
Fuel Injection Timing 10.49 °CA
(The timing difference of oil supply in each cylinder is 1°CA)
Starting Air Pressure Air bottle pressure: 3.0;
After the relief valve pressure: 1.0
Dimensions ( L × W × H ) 5992×2317×3660 mm
(Only reference, please refer to the drawing)
Lifting Height Of Cylinder 3040 mm (Without cylinder head bolt) /
3482 mm (With cylinder head bolt)
Weight (About) 36300 kg Crank Arrangement
1.8
3.6
4.5
2.7
Noise Level (Sound Pressure Level) < 100 dB(A)
——END——

ZC8270ZLC Series Marine Engine Dimensions

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.

The picture of Sale Manual showing the accessories and scopes of supply.

Sale Manual

The picture of Installation Drawing showing the accessories and scopes of supply.

Installation Drawing

The picture of Installation Manual showing the accessories and scopes of supply.

Installation Manual

The picture of Operation Manual showing the accessories and scopes of supply.

Operation Manual

The picture of Engine Parts Catalogue showing the accessories and scopes of supply.

Parts Catalogue

The picture of Test Report and Certifcate showing the accessories and scopes of supply.

Report & Certifcate
