ZICHAI ZDMO1400PNOB Generator Set

The ZDMO1400PNOB is a high-power, high-reliability diesel generator set, specifically engineered for large vessel propulsion, heavy industrial operations, and emergency power supply scenarios. Built on mature low-speed diesel engine technology and advanced power generation control systems, it delivers efficient and stable power output, providing users with long-lasting, dependable energy solutions.

The code Z in the model name indicates that the engine brand of the unit is ZICHAI, the code D in the model name indicates that the fuel type is diesel, the code M in the model name indicates that the Marine-used, the code O in the model name indicates that the open type, the code 1400 in the model name indicates that the power is 1400KW, and the code P in the model name indicates that the power type is the primary power. The code N in the model name indicates that the generator brand is SinoGen, the code O in the model name indicates that the generator set has no ATS and no parallel function, and the code B in the model name indicates that the frequency of the generator set is 60hz.

As official exporting agent of ZICHAI, SinoGen is a professional power system solution provider, we provide one-stop power system solutions for customer from all over the world, from power system design to power system supply, from installation to commissioning, from after-sales services support to parts supply, SinoGen is your reliable power system partner that give you best value for money and reliable system solution.

Advantages of Generator Set ZDMO1400PNOB

Delivers a rated power of 1400 kW and standby power of 1540 kW, paired with the 6N260ZLD-2 diesel engine (1544 kW continuous power) at 720 rpm, reliably meeting heavy industrial and marine high-load demands.
Optimized combustion design achieves a fuel consumption rate of only 196 g/kW·h and a lube oil consumption rate of 0.9 g/kW·h, significantly cutting long-term operating costs while ensuring efficient performance.
Features automatic voltage regulation and a brushless self-excited system, with voltage regulation ratios of ±2.5% (single unit) and ±2.5% (parallel operation), maintaining stable 60 Hz output ideal for sensitive industrial and marine systems.
Rugged construction withstands harsh marine and industrial environments, supporting startup methods (compressed air) for seamless integration into diverse power networks.

Technical Specifications

Generator Model:	ZDMO1400PNOB
Engine Model:	6N260ZLD-2
Rated Power:	1400 kW
Rated Speed:	720 rpm
Fuel Consumption Rate:	196 g/kW·h
Paralleling Capability:	Supported, voltage regulation ±2.5%
Cylinder Bore:	260mm
Rated Frequency:	60 Hz
lubrication Consumption:	0.9 g/kW·h
Cylinder No.:	6
Starting Air Pressure:	3MPa

coming soon

Generator Model	Rated Power	Engine Model	Rated Speed	Fuel Consumption
ZDMO1400PNOA	1400kW @ 750 rpm	6N260ZLD	750 rpm	196 g/kW·h
ZDMO1400PNOB	1400kW @ 720 rpm	6N260ZLD-2	720 rpm	196 g/kW·h
ZDMO1500PNOA	1500kW @ 750 rpm	6N260ZLD-1	750 rpm	196 g/kW·h
ZDMO1500PNOB	1500kW @ 720 rpm	6N260AZLD-3	720 rpm	195 g/kW·h
ZDMO1600PNOA	1600kW @ 750 rpm	6N260AZLD-8	750 rpm	195 g/kW·h
ZDMO1600PNOB	1600kW @ 720 rpm	6N260AZLD-7	720 rpm	195 g/kW·h
ZDMO1700PNOA	1700kW @ 750 rpm	6N260AZLD-10	750 rpm	195 g/kW·h
ZDMO1700PNOB	1700kW @ 720 rpm	6N260AZLD-9	720 rpm	195 g/kW·h
——END——

General Information of ZICHAI ZDMO1400PNOB Generator Set
Rated Power	1400 kW	Stand-by Power	1540 kW
Rated Frequency	60 Hz	Rated Power Factor (cos φ)	0.8 Lagging
Stationary Voltage Regulation Ratio	±2.5%	Adopted Diesel Engine Type	6N260ZLD-2
Continuous Power of Diesel Engine	1544 kW	Maximum Power of Diesel Engine	1698 kW
Rated Speed of Diesel Engine	720 rpm	Fuel Consumption	196 g/kW·h
Lube Oil Consumption	0.9 g/kW·h	Cylinder No.	6
Cylinder Bore	260 mm	Starting Mode	Compressed air
Starting Air Pressure	3 MPa
——END——
